The Kantronics KPC-3+ is engineered for dependable and versatile digital communications. This unit reflects many years of Kantronics experience and is built with an eye toward emerging applications. The KPC-3+ can fill a variety of roles. In use around the world, Kantronics Packet Communicators set the standard by which others are measured!
SignaLink™ USB Interfaces support all computer program digital modes and digital voice modes, WITHOUT using your computer sound card! This includes legacy modes, such as RTTY, SSTV, and CW, as well as today's most popular modes, including FT8, PSK31, JT65, JT9, FSK441, MSK144, WSPR, Olivia, EchoLink Node and hundreds more! Finally got the Standard Comm port to work. When I went to couple the SignaLink to my desktop computer running Windows 10, after the install it showed me Standard Comm Port on COM3 and Enhanced Comm Port on COM4, but then they disappeared and I have not been able to get ANY virtual port to show up since, even with an Uninstall/Reinstall sequence.
- Signalink Software Download. Signalink Usb Manual. Connecting Signalink To Windows 10. Signalink Driver Download. Signalink Usb Windows 10 Setup. Signalink Usb Drivers Download. Signalink Setup Windows 10. Signalink Usb Audio Codec Download.
- When the signalink is connected to the USB port, Windows 10 should automatically provide a USB audio driver. That hasnt happened. In checking the device driver I find that there is no USB Audio codec on the computer.
Instead of the DB25 RS232 jack, it now has an up-to-date universal serial jack. You will need a common-type cable, that has a USB type A (computer end) to USB type B (KPC end). Because of this change in the computer interface, there will be a few differences in operations and functions. Some of the options under the INTFACE command, while still available, will be limited or non-functional. The options for GPS, KISS, XKISS, MODEM, and NET may not be useable, or may have limited functionality.
The ability of being able to use KISS mode with the KPC-3+ 512K USB, solely depends on the computer software you use, and ITS ability to communicate through the virtual serial port that your computers operating system configures when it sees the USB connection to the KPC.
SO, if your operating system recognizes the KPC-3+ 512K USB version, AND assigns a com port number for programs to use to communicate, AND your KISS mode software can communicate through that assigned serial port number, there will be no difference in the KPC operation, from the previous RS232 model.
Interfacing with an external GPS or weather station device through the serial port is no longer available. The only GPS interface is through pin 2 on the radio port, and is enabled with the GPSPORT command.
Interfacing the KPC into a node stack with other TNCs is no longer available. Interfacing to a computer running as a network node should work as long as the computer program used can access the virtual serial port assigned to the KPC by the computers operating system.
Option jumpers. Only J7, J8, and J10 are changed. J8 and J10 connect analog inputs from the DB9 jack through to the processor. Optionally, open those jumpers to disable those inputs. J7 selected those analog inputs either from the DB9 or the DB25 jack. Since there is no longer a DB25, J7 was removed.
Driver- the computer interface chip inside this KPC-3 Plus is made by FTDI. If your computer operating system does not include a serial port driver for this interface chip, you can get one from the chip makers web site at:
Reversed power protection has been added to the power input circuit. Make sure you either use a current-limited power source, or include a small fuse in the power lead. The KPC typically draws less than 50ma. The power jack polarity is center-positive.
- 'Keyboard to keyboard' communications
- Digipeater
- Personal Mail Box
- Local area node
- Remote control devices
- Remote access of telemetry
- Network node operation
- BBS operations and message forwarding
- GPS position transmitting and tracking (requires external GPS receiver with NMEA-0183 data output)
- Data storage and retrieval
- EMWIN Weather Information (additional software required)
Usb Driver Download
You can carry a KPC-3+ into the field with a radio to form a mobile data terminal, or (with the addition of an external GPS receiver) a GPS mobile 'tracker'. Its flexible power requirements (6 ~ 25 Vdc) allow for maximum versatility. You can achieve many hours of use by installing a 9 volt battery inside the KPC-3+. Battery life can be extended by disabling the LED displays through a simple keyboard command.
- 'NEWUSER' mode provides a quick start for packet newcomers
- Large capacity internal mailbox and mail forwarding feature
- GPS operation mode allows use with APRS® or other geolocation software
- Remote Control and telemetry functions with two A/D inputs and two control line outputs
- Low power requirements (9 volt battery power capability)
- Network node functions with standard 'KA' Node and K-Net Node™
- BBS, KISS, XKISS, HOST, TERMINAL, GPS and MODEM operating mode
- 'Online' HELP feature
- Upgradeable as new firmware is released
- Digital control of audio drive level -- set from keyboard or by remote control
- Motorola® HC11 central processor
- 512k memory standard (since 2nd quarter 2011)
- Comes with data connector, data wire, coaxial power plug, detailed manual & software
- Usable with base, mobile or hand-held radios
Signalink Usb Manual Windows 10
| . | |
|---|---|
| Dimensions (H×W×D) | 0.8'×5.2'×5.2' (21 mm × 133 mm × 133 mm) without projections |
| Weight | 11 oz (0.32 kg) |
| Power Requirements | |
| Voltage | DC 6 V to 25 V |
| Current | < 30 mA (LEDs on, unit active)< 15 mA (LEDs off, unit inactive) |
| External Power Connector | 2.1 mm coaxial, center pin positive |
| Internal Power Connector | Circuit board accommodates user-installed 9 V battery connector |
| External Signal Ports | DB-9 female (radio port)USB type B or DB-25 female RS232 (Computer port) |
| PTT Watchdog Timer Period | approx. 2.5 minutes |
| External Carrier Detect | Pulldown to ground |
| Analog Measurement Inputs(A/D Converter) | Two inputs; 0 V to +5 V, 8-bit accuracy |
| Data Rate (radio port) | 1200 bps (default); 300, 400, 600 |
| PTT Output | Open drain, max +50 V dc, max 200 mA |
| Audio Output Level | Continuously adjustable from 1 mV p-p to 4 V p-p |
| Audio Output Impedance | 600 Ohm, AC coupled |
| Modulation | 1200 bps FSK full duplex CCITT V.23 |
| Audio Input | 1300 Hz/2100 Hz |
| Sensitivity | 5 mV p-p |
| Dynamic Range | 70 dB |
| Input Impedance | Unbalanced, 10 kOhm(600 Ohm with jumper J 3 installed) |
| Max Audio Input Voltage | ±12 V dc; 35 V p-p sinusoidal |
| Operating Modes | Packet, WEFAX, KISS, XKISS, HOST, GPS, MODEM (RX only) |
| LED Indicators | Power, Xmit, Rcv, Connected, Status, Mail(user option on/off) |
| Remote Control Access | All controller functions, user-defined password |
| External Reset | Pulldown to ground |
| Operating Protocols | AX.25 Levels 1 and 2 (user-selectable) |
| Compliance | FCC Class B |
Signalink Usb Driver Windows 10 32 Bit
Specifications subject to change without notice or obligation.
APRS® is a registered trademark of Bob Bruninga, WB4APR.
All registered trademarks remain the property of their respective owners.
